Product Details:
|
| Model NO.:: | EN-130JK | Material Thickness:: | 0.4-0.7mm |
|---|---|---|---|
| Rolling Speed:: | 6-15m/Min | Roller Stations:: | 14 Stations |
| Hydraulic Cutting Power:: | 5.5kw | Material Of Shaft:: | 45 Steel |
| Transport Package:: | Plastic Film, Container | HS Code:: | 845522100 |
| High Light: | 0.7mm corrugated iron sheet making machine,12m/min corrugated iron sheet making machine,corrugated iron roofing sheet making machine |
||
Working flow
|
NO.
|
Description
|
Quantity (set)
|
Remark
|
|
1
|
5Tmanual decoiler
|
1
|
As one complete part
|
|
2
|
Guiding device
|
1
|
|
|
3
|
Pre-cutter
|
1
|
|
|
4
|
Forming system
|
1
|
|
|
5
|
Transmission system
|
1
|
|
|
6
|
Hydraulic guillotine
|
2
|
|
|
7
|
Support table
|
2
|
|
|
8
|
Hydraulic station
|
1
|
|
|
9
|
Control box
|
1
|
|
|
10
|
Spare parts and tools
|
1
|
As attaching list
|
roll forming
| No. | Spc. | |
| 1 | Suitable to process | Color steel plate |
| 2 | Width of the plate | 410mm |
| 3 | Rollers | 15rows |
| 4 | Main power | 4kw |
| 5 | Hydraulic | 5kw |
| 6 | Thickness of the plate | 0.3-0.6mm |
| 7 | Productivity | 8-10m/min |
| 8 | Diameter of the roller | Φ70mm |
| 9 | Roller material | 45# steel polished and coated with chrome HRC55-60° |
| 10 | Shaft material | high grade No.45 steel after treatment |
| 12 | Blade material | Cr12 steel after treatment |
| 13 | Voltage | 380V 50Hz 3phases |
| 14 | Hydraulic | 40# |
| 15 | Processing precision | Within 2.00mm |
| 16 | Control system | PLC Frequency Control System with touch screen |
Cutting
(1)Material for Cut-Off Modular:Cr12 steel after treatment
(2)Hardness for Heat Treatment:HRC55 – 60°
(3)Cut-Off Type: Hydraulic, Automatic Cut-Off
(4) Motor for Hydraulic Stand: 3 kw
PLC
| Main item | Parameter detail |
| PLC | Delta(standard) or according to your request |
| Inverter | China brand(standard) or according to your request |
| Touch screen | Mcgs(standard) or according to your request |
| Encoder | China brand(standard) or according to your request |
| Voltage/HZ/Phase | 380v/50-60hz/3phase |
Hydraulic pump
| Main Item | Parameter detail |
| Motor | 3kw China brand or according to your request |
| Pump | China brand or according to your request |
| Solenoid valve | China brand or according to your request |
| Cooling system | Cooling fan |
AQ
1) Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available across the world. We need your machines running in order to keep your business running.
2)Q: How do your machines compare with other big companies in this market?
A: We are up to date with the latest technology and improve our machines accordingly
