Product Details:
|
| Tile Type:: | Colored Glaze Steel | Model Number:: | Light Keel Roll Forming Machine |
|---|---|---|---|
| Thickness:: | 0.3--0.8mm | Dimension(L*W*H):: | 4.5m*1.2m*1.2m |
| Roller Material:: | 45# Forged Steel | Power(W):: | 4+4KW |
| Suitable To Process:: | Color Steel Plate | Control System:: | PLC Control |
| Warranty:: | 12 Months | ||
| High Light: | glazed tile roll forming machine,sheet metal roll forming machines |
||
Manual uncoiler-- roll forming machine-- PLC control box-- hydraulic cutter- output table
| Article No. | Item Name | Specification |
| 1 | Width of feeding material | 1000 mm coil sheet |
| 2 | Thickness of feeding material | 0.3-0.8 mm coil sheet |
| 3 | Roller station | 8-15 stations |
| 4 | Shaft Diameter | 45-65 mm |
| 5 | Productivity | 8-12 m/min |
| 6 | Rollers' material | 45# steel forge |
| 7 | Shaft material | 45# steel |
| 8 | Weight | 3.5-8 tons |
| 9 | length | 5.5-11m |
| 10 | Voltage | 380V 50Hz 3phases |
| 11 | Control | PLC |
| 12 | Decoiler | 5 tons |
| 13 | Motor | 3-5.5 kw |
| 14 | Driving way | Chain transmission |
| 15 | Chain size | 0.6-2 inch |
| 16 | Cutting system | Hydraulic cutter |
AQ
1. How to maintain the machine?
Answer: add mechanical lubrication equipment to chain, bearing and cutting slide every month. Add mechanical lubrication to the case every half a year.
2. Do you sell only standard machines?
A: No, most of our machines are built according to customers specifications, using top brand name components.
3. How many workers to operate the machine?
A:Only 1-2 workers.
4. How to visit your company?
a.Fly to Beijing airport: By high speed train From Beijing Nan Station to Cangzhou West Station(1 hour), then we can pick you up .
b.Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou West station(4.5 hours), then we can pick you up.
5. What can you do if the machine broken?
Our machine's warranty period is 12months,if the broken parts can't be repaired,we can send the new parts to replace the broken parts for free,but you need pay the express cost yourself.if over warranty period,we can for to solve the problems via negotiation,and we supply the technical support for the whole life of the equipment.
6. How can I trust you that machines pasted testing running before shipping?
A: 1) We record the testing video for your reference. Or,
2) Please visit company and test machine if convenient.
