Product Details:
|
| Model NO.:: | EN-130JK | Material Thickness:: | 0.4-0.7mm |
|---|---|---|---|
| Rolling Speed:: | 6-15m/Min | Roller Stations:: | 14 Stations |
| Hydraulic Cutting Power:: | 5.5kw | Material Of Shaft:: | 45 Steel |
| Transport Package:: | Plastic Film, Container | HS Code:: | 845522100 |
| High Light: | corrugated sheet roll forming machine,glazed tile roll forming machine |
||
Metal Roof Roll Forming Machine 3 Phase 380V For Roofing Cladding 8-15M/Min
What is the application of roofing sheets machine manufacturers?
roofing sheets machine manufacturers is mainly producing steel roof/ wall sheet .The final products have teo types,corrugated sheet andtrapezoidal sheet.As we know, steel roof/ wall sheet is widely used in large span factory building, warehouse, office buildings, villas, roof, cold storage, air purification room, stores, kiosks, and temporary housing.
What is the advantage of roofing sheets machine manufacturers?
1. The system is easy to operate and use. PLC: Delta(Can customize as customer require)
2. the surface of the final product is very smooth and beautiful without any scratch on the surface.
3. customized:design the machine according to your specification and profile drawing.
What is the specification of roofing sheets machine manufacturers?
| Item | Specification |
| name | roofing sheets machine manufacturers |
| Processing material | color steel,GI,PPGI |
| Processing thickness | 0.3-0.8 mm |
| Diameter of shaft | Φ80mm |
| Electric tension | as the customer's requirements |
| Roller | High grade 45# forged steel (plated chrome plating on surface) |
| coil thickness | 0.05mm |
| Processing precision | within 1mm |
| Transmission | By chain(1inch) link |
| Hydraulic cutting | Controlled by PLC |
| PLC | DELTA(TAIWAN) |
| Material of blades | Cr 12, quenching 58-62℃ |
| Switch | CHNT |
| roller station | to the finnal design |
FAQ:
1. How to get a quotation of double layer metal roof tile making machine?
Give me the profile drawing and thickness ,this is the important.
Other spicific requirements is welcome,such as the speed,power and voltage you want.
2. Terms of payment:
30% T/T, Balance to be paid before shipping after inspection.Also we accept the payment L/C, O/A , D/P.
3. How long the double layer metal roof tile making machinecould be made?
Normally speaking, double layer metal roof tile making machinecould be made without 45 working days. If you need double layer metal roof tile making machinein a hurry, we can make it for you less than a month.
