Metal Profile Stud Rolling Making Forming Machine Precision Engineered 1.5mm

Metal Profile Stud Rolling Making Forming Machine Precision Engineered 1.5mm
Metal Profile Stud Rolling Making Forming Machine Precision Engineered 1.5mm Metal Profile Stud Rolling Making Forming Machine Precision Engineered 1.5mm Metal Profile Stud Rolling Making Forming Machine Precision Engineered 1.5mm Metal Profile Stud Rolling Making Forming Machine Precision Engineered 1.5mm Metal Profile Stud Rolling Making Forming Machine Precision Engineered 1.5mm

Large Image :  Metal Profile Stud Rolling Making Forming Machine Precision Engineered 1.5mm

Product Details:
Place of Origin: China
Brand Name: ZTRFM
Certification: CE, SGS
Model Number: 002
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Nude with anti-rusting coil
Delivery Time: 60 WORKING DAYS
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 30 SETS/MONTH

Metal Profile Stud Rolling Making Forming Machine Precision Engineered 1.5mm

Description
Voltage: 380V ,50Hz, 3Phase (as Customer Request) Frame Type: Memorial Arch Frame Of Thickness 30mm
Material Of Rollers: GCr12mov Diameter Of Shafts: Φ70mm
Roller Station: 15 Material Thickness: 0.5-1.5 Mm
High Light:

1.5mm Stud Making Machine

,

Stud Making Machine 1.5mm

,

Precision Engineered Stud Making Machine

                                         Metal profile stud rolling forming machine

Metal profile stud rolling forming machine is designed to make the metal profiles in batch fully automatically. Metal profiles are precision-engineered, high-quality steel sections that are used to form the metal substructure of the Drywall or ceiling Systems. All metal sections produced from high-grade hot dip galvanized steel coils with the cold rolled forming process by the rolling forming machine. Here we will take some random drawing to show you how the metal profile rolling forming machine is designed.

Metal profile of stud drawing

Sturdy 0.6 mm sections with full set of compatible accessories

Part of a complete ceiling system

Only one type of channel for main and furring functions

Increased web width for faster/easier installations and smoother joints



Where to use of those profiles:

stud usage

stud drywall



Metal profile stud rolling forming machine

metal stud rolling forming machine

Metal profile stud rolling forming machine parameters and options for your reference.

1. We have the following speed options for your reference:

Normally 25 to 35 meter per minute without punching

High speed is from 50 to 75 meter per minute with punching

Highest speed now we can reach 120 meter per minute with punching.

Adjustment options.

We have manual adjustment by spacer.

We have PLC control fully automatic type.

The machine working flow like this:

working flow



Note: We use split rollers to realize one machine to produce C products with different bottom widths.
Voltage 380V ,50Hz, 3Phase (as customer request)
Frame type Memorial arch frame of thickness 30mm
Drive mode Heavy duty gearbox as transmission
Material of rollers GCr12mov
Material of shafts 45# steel with tempering
Diameter of shafts Φ70mm
Number of rollers 15 rollers With more rib roller one more station
Main power 7.5 kw and with one more motors 11kw
Raw Materials of the steel coil Galvanized steel plate
Material thickness 0.5-1.5 mm
Forming speed 50 m per minute without punching hole




The following we share the manual adjustment machine. The advantages of it, that manual adjustment cost is more lower and if you have the engineers who are professional for machines, manual adjustment will be best options.

roller station

If you need to add the punching or the embossing, we can also add for you. We can design the dotting embossing or various types holes either non-stop or stop punching.



Here is the machine working speed of Metal profile stud rolling forming machine for your reference:
