Product Details:
|
| Type:: | Tile Forming Machine | Production Capacity:: | 8-20m/min |
|---|---|---|---|
| Dimension(L*W*H):: | 8m*1.5m*1.2m | Power(W):: | 5.5kw |
| Operation Style:: | Full Automatic | Control System:: | PLC Control |
| Equipment Base:: | 360H Steel Frame | After-sales Service Provided:: | Engineers Available To Service Machinery Overseas |
| High Light: | sheet roll forming machine,corrugated iron sheet making machine |
||
drive: manual
Inner Diameter: 450-550mm
Outer Diameter: max 1600mm
Max Coil width: 1250mm
Carrying capacity: 5 T
Forming steps : 13 rollers
Shaft diameter: 80mm
roller material: 45# steel with tempering
shaft material: 40Cr steel
Transport : By chain
Type of cutting and punching: Hydraulic
Cutting tolerance: ±1mm
Cutter quantity: 2 set
Material of blades: Gcr12 quenched
Power supply : hydraulic power
Frame : Pillar style with rack & pinion system
Stroke switch : non-contact photoelectric switch
Hydraulic oil: 46#
Hydraulic power: 3kw
Cutting length : As required
feasure: no distorting or wasting. High level safety factor
|
Packaging
|
|
|
Packaging Details
|
1.One 20ft or 40ft container for loading one set machine with manual decoiler.
2.The whole wiped anti rust oil ,PLC controller covered by foam film.
3.Spare parts and some small parts packed in plastic tooling box.
4.All components of Deck Roll Forming machine fixed by steel wire.
|
c. There need one technician. for one week.
