Direct Source Combined Light Keel Roll Forming Machine Ceiling Strut Channel
Product Description
T bar suspended ceiling grid
| Machine Description | Quantity | Delivery time | Container Type |
Price/ USD (FOB TIANJIN) |
| T bar suspended ceiling grid |
1 SET |
45 working days | 1*20GP |
13500---42500
|
The specification of ceiling t grid roll forming machine
| No. | Main parameter of T bar suspended ceiling grid | |
| 1 | Product name | T bar suspended ceiling grid |
| 2 | Length of the main part | 3600*800*1400mm |
| 3 | Weight of main part | 3.2 T |
| 4 | Voltage | 380V-50HZ-3P (as customer’s request) |
| 5 | Machine structure | Vertical memorial frame |
| 6 | Frame | Memorial arch frame type  |
| 7 | Frame thickness | 25mm |
| 8 | Drive mode | By Gear |
| 9 | Material of rollers | Cr12 |
| 10 | Material of shafts | 45# steel with tempering |
| 11 | Diameter of shafts | φ40mm |
| 12 | Number of rollers | 16 rollers |
| 13 | Main power | 4kw (Cycloidal planetary gear speed reducer) |
Packing list
The accessories for
| No. | Name | Unit | Qty |
| 1 | 1.5T Manual decoiler | set | 1 |
| 2 | Main forming machine | set | 1 |
| 3 | PLC control system | set | 1 |
| 4 | Hydraulic pump station | set | 1 |
| 5 | Post cut&punching unit | set | 1 |
| 6 | Electric motor | set | 1 |
| 7 | Output table | set |
1
|
Company Information
Cangzhou Kingter Roll Forming Machinery Co., Ltd is a professional manufacturer and exporter of cold roll forming machines. All products comply with international quality standards and are greatly appreciated in markets throughout the world, such as Asia, Africa, Europe,South America, Australia and so on.
We specialized in manufacturing Color steel roll forming machinery, C U M Z purlin roll forming machine, Glazed tile roll forming machine,floor deck roll forming machine, shutter door roll forming machine, highway guardrail roll forming machine, downspout machine, welding pipe machine. For metal processing, we have slitting machine, cutting machine, decoiler, punching machine and others.
