Detailed Product Description
Tile Type:: Colored Steel Dimension(L*W*H):: 8000*1520*1500mm
Power(W):: 15kw Voltage:: 380v Or Any
Raw Material Thickness:: 1.5-3 Mm Roller Material:: 45# Forged Steel
Material Of Cutting Blade:: Cr12 Shaft Material:: Bearing Steel

Punching Device U Channel Roll Forming Machine , Galvanized Steel Roll Forming Machine



Equipment Description



1. The Chart of Process flow

1.2mm-3mm Q195-235 Blue C Z Purlin Roll Forming Machine With 17 Forming Roller

Manual de-coiler --- Electric Feeding --- Servo motor feeding ----oll Forming Machine------Computer Control Cabinet---Automatic cutting Mechanism ---Run-out Tables



2. The equipment including

Roll forming machine 1 set
Hydraulic cutter 1 set
Electrical control system 1 set
Hydraulic system 1 set
Normal run out table 3 PC 1m*1m
Manual de-coiler 1 set Max. loading 5 T





roll forming machine

Item Parameter detail
Processing Material GI and Black Coils
Material thickness 1-3mm(standard), 3-5mm(customized)
Machine frame 360#H steel, Adopt diagonal line welding, leveling instrument measurement to make sure the final frame is high-precision
Machine siding panel
Plate type Casting Pillar type(option)
Punching Device U Channel Roll Forming Machine , Galvanized Steel Roll Forming Machine Punching Device U Channel Roll Forming Machine , Galvanized Steel Roll Forming Machine
Plate thickness:20mm Pillar thickness:35mm



Forming stations 13-18 stations (according to the material thickness)
Machine rollers high grade Gcr15 forged steel(bearing material), Hard quenching and hard chroming with thickness 0.05mm
Processing way:cutting--drilling--CNC lathing--quenching--CNC lathing--chroming
Machine Shaft φ80-90mm high garde No.45 steel after treatment,
Machine spacers CNC lathing in high-precision and wire-electrode cutting
Machine bearings China Haerbin bearing or SKF international bearing(option)
Driving system 2 inch chain or gear box(option)
Machine power 7.5kw-22kw(according to the size and thickness)
Machine working speed without punching:8-12m/min or 10-30m/min(option)
Machine testing method After machine installation, we will test it ourselves, compare with the profile drawing, the difference is controlled in 0.5mm


Punching device

Item Parameter detail
Frame processing the whole levelling surface is made by drilling machine
Mould material Cr12mov
Mould processing wire eletrode-cutting for the mould shape, it will save pressure
Hole size According to your request
Hole number According to your request
Pressure 20Mpa


Cutting device


(1) Material for Cut-Off Modular:Cr12 steel
(2) Hardness for Heat Treatment:HRC60 – 65
(3) Cut-Off Type:Hydraulic, Automatic Cut-Off
(4) Cut-Off Modular:1 set
(5) Motor for Hydraulic Stand: 3 kw
