High-Speed CZ Purlin Roll Forming Machine with Automatic Quick Change

The High-Speed CZ Purlin Roll Forming Machine with Automatic Quick Change is an advanced cold roll forming solution designed for the efficient production of both C and Z purlins on a single production line. Equipped with a fully automatic quick-change system, servo-driven feeding, hydraulic punching, and intelligent PLC control, the machine enables rapid profile conversion without replacing forming rollers, significantly reducing downtime and increasing productivity.

Designed for steel structure manufacturers, industrial buildings, warehouses, solar projects, and commercial construction, this machine delivers exceptional forming accuracy, high production speed, and reliable continuous operation.

Category:

One Machine for Both C & Z Purlins

Traditional purlin production often requires multiple machines or time-consuming manual adjustments. Zhongtuo's automatic quick-change technology allows operators to switch between C and Z profiles within minutes through the PLC control system.

Benefits

  • Automatic C/Z profile conversion
  • No roller replacement required
  • Reduced setup time
  • Higher production efficiency
  • Lower labor costs

Fully Automatic Size Adjustment

The machine automatically adjusts the profile width according to the selected production parameters.

Supported production ranges can be customized, such as:

  • C80–C300
  • Z100–Z300
  • Other customized dimensions available

The servo-controlled positioning system ensures precise and repeatable adjustments.

High-Speed Production

Engineered for maximum output, the production line combines high-speed roll forming with synchronized punching and cutting systems.

Features

  • Continuous high-speed production
  • Stable forming performance
  • Accurate length control
  • High output with minimal downtime

Ideal for large-volume production environments.

Precision Roll Forming System

The forming rollers are CNC-machined, heat-treated, and chrome-coated to provide excellent wear resistance and long service life.

Advantages include:

  • Consistent profile dimensions
  • Smooth finished surface
  • High dimensional accuracy
  • Long-lasting forming rollers
  • Stable operation under continuous production

Hydraulic Punching System

The machine supports multiple punching configurations to meet various structural requirements.

Available punching options include:

  • Web holes
  • Flange holes
  • Slotted holes
  • Round holes
  • Customized punching patterns

Punching positions are automatically controlled through the PLC system for maximum accuracy.

Hydraulic Flying Cutting

The flying cutting system synchronizes with the production speed, allowing continuous operation without stopping the machine.

Benefits:

  • Burr-free cutting
  • Precise length accuracy
  • Higher production efficiency
  • Reduced material waste

Intelligent PLC Control System

A modern touchscreen interface simplifies operation and improves production management.

Functions include:

  • Automatic profile selection
  • Automatic width adjustment
  • Production length setting
  • Quantity counting
  • Recipe storage
  • Fault diagnosis
  • Production monitoring
  • Emergency protection

Heavy-Duty Machine Construction

Built with a reinforced steel frame and precision-machined components, the machine is designed for long-term industrial use.

Construction features include:

  • Heavy-duty welded frame
  • High-strength transmission system
  • Precision shafts and bearings
  • Reliable hydraulic station
  • Stable operation at high speed

Applications

The High-Speed CZ Purlin Roll Forming Machine is widely used for producing:

  • C Purlins
  • Z Purlins
  • Structural Steel Members
  • Warehouse Frames
  • Steel Building Structures
  • Industrial Workshops
  • Agricultural Buildings
  • Commercial Construction
  • Solar Mounting Structures
  • Prefabricated Buildings

Key Features

  • Automatic C/Z profile conversion
  • Fully automatic quick size adjustment
  • High-speed continuous production
  • Servo feeding system
  • Precision roll forming technology
  • Hydraulic punching system
  • Hydraulic flying cutting
  • PLC touchscreen control
  • Heavy-duty industrial construction
  • Custom profile solutions available

Why Choose Zhongtuo?

Zhongtuo specializes in high-performance roll forming equipment for customers worldwide. Our High-Speed CZ Purlin Roll Forming Machine is designed to maximize production efficiency while minimizing setup time and maintenance costs.

Zhongtuo Advantages

  • Automatic quick-change technology
  • High-speed, high-precision production
  • Customized machine configurations
  • Professional engineering support
  • Strict quality control
  • Worldwide installation and commissioning
  • Comprehensive after-sales service
  • Reliable long-term performance

Whether you require flexible production for multiple purlin sizes or high-volume manufacturing with minimal downtime, Zhongtuo provides a dependable solution tailored to your production needs.

Request a Quote

Looking for a high-efficiency CZ Purlin Roll Forming Machine with automatic quick change?

Contact Zhongtuo today for:

  • Customized machine configurations
  • Profile drawing confirmation
  • Technical specifications
  • Factory-direct quotation
  • Global shipping and installation support
