Aluminum Galvanized Floor Decking Roll Forming Machine Width With Pre - Cutting
material:
Processing material: colored steel plate, galvanized plate, or aluminum plate
Material thickness: 0.8---1.2mm
Material hardness: 195 mpa---350 mpa
Material width: 1250mm
Formed width: 914mm
Wavelength: 305 mm
Step height: 75mm
Step length: 150mm---380mm(adjustable)
Forming speed: 8-10m/min
Uncoiler
Usage:It is used to support the steel coil and uncoil it in a turnable way.
Passive uncoil pulled by roll forming system
Loading capacity: 5T
Uncoiling width: 1250mm
Inner diameter: 450-550mm
Entry Beach
Length of the main part:about 1800*1450*1500mm
Weight of main part: 8.5T
Voltage: 380V/50HZ 3Phase
Roller fixer: middle plate
Frame: 350H steel
Drive mode: chain
Material of rollers: 45#steel, surface hard chromium plating.
Material of shafts: 45#steel
Diameter of shafts: φ 90mm
Number of rollers: 28 rollers
Main power: 2*11kw
Material of mould:Cr12 quenched
Power supply:hydraulic power
It adopts the hydraulic drive and automatic location to decide the dimension and cut the target products.
Material of blades: Cr12 quenched
Power supply : hydraulic power
Components:It contains one set of blade, one hydraulic tank and one cutter machine.
Power:5.5kw
4. Our after-sale service:
Our products are widely used in various industrial factory ,beauty spot, holiday village building, hotel,exhibition ,easy steel building manufacturing ,and have features such as nice appearance and durable.
Within in one year if any parts go broken we will send new ones to replace for free,after the warranty period,we will help you repair the machine ,you only responsible for the labour and parts if the machine have some problems.
